Machine Type

Monochrome A4 Laser Multifunctional

Core Function

iR 1643iF II: Print, Copy, Scan, Send and Fax iR 1643i II: Print, Copy, Scan and Send

Control Panel

12.7 cm (5in) TFT LCD WVGA Colour Touch panel

Memory

Standard: 1.0 GB RAM

Storage

eMMC: 2 GB

Interface Connection

NETWORK: 1000Base-T/100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n), Wi-Fi Direct Connection OTHERS: USB 2.0 (Host) x2, USB 2.0 (Device) x1

Memory Media

USB Memory

Network Security

TLS 1.3, IPSec, IEEE802.1X authentication, SNMPv3, Firewall, Functionality (IP/MAC Address Filtering), Enabling/Disabling (Network Applications, Remote UI, USB Interface), G3 FAX separation from LAN, USB Port separation from LAN

Document Security

Print Security (Secure Print, uniFLOW Secure Print^*1), Scan Security (Encrypted PDF, Device Signature PDF/XPS), Send Data Security (Restricted E-mail/File send functions, Security Confirming FAX number, Allow/Restrict Fax Driver Transmissions, Allow/Restrict Sending from History)

Paper Supply Capacity (A4, 80 g/m²)

Standard: Paper Cassette: 550 sheet Multi-purpose tray: 100 sheet Maximum: 2,300 sheets (with PAPER FEEDER PF-C1x3)

Paper Output Capacity (A4, 80 g/m²)

Standard: 150 sheets

Toner

Toner T06 Black

Supported Media Sizes

Upper Cassette 1: Standard size: A4, B5, A5, A5R, A6 Custom size: Minimum 105.0 x 148.0 mm up to 216.0 x 355.6 mm Multi-purpose tray: Standard size: A4, B5, A5, A5R, A6 Index Card, Envelopes [No. 10 (COM 10), Monarch, ISO-C5, DL] Custom Size: Minimum 76.2 x 127.0 mm up to 216.0 x 355.6 mm

Supported Media Weights

Upper Cassette 1: 60 to 120 g/m² Multi-purpose tray: 60 to 199 g/m² Duplex: 60 to 120 g/m²

Warm-up Time

From Power On: 14s or Less^*2 From Sleep Mode: 4s or Less

Dimensions (W x D x H)

480 x 464 x 452 mm

Installation Space (W x D)

480 x 905 mm (With cassette open)

Weight

Standard: Approx. 20.0 kg (Including toner)

Print Speed (BW)

1-sided: Up to 43/43 pages per minute (A4) 2-sided: Up to 36/36 pages per minute (A4)

Print Resolution (dpi)

600 × 600

Page Description Languages

Standard: UFR II, PCL6, PCL5 Adobe®PostScript®3™ (Optional iR1643i II)

Direct Print

Direct printing available from USB memory, LPR Supported file types: TIFF, JPEG, PDF and XPS (only LPR)

Printing from Mobile and Cloud Application

Apple AirPrint, Canon PRINT Business, Mopria and uniFLOW Online

Operating System

UFRII: Windows® 8.1/10/Server 2012/Server 2012 R2/Server 2016/Server 2019, MAC OS X (10.11 or later) PCL: Windows® 8.1/10/Server 2012/Server 2012 R2/Server 2016/Server 2019 PS: Windows® 8.1/10/Server 2012/Server 2012 R2/Server 2016/Server 2019, MAC OS X (10.11 or later)
